Page 144 - MIGHTY - CATALOGUE 2014-2015
P. 144

139          Mighty Lighting






                                           RECESSED SQUARE DOWNLIGHT


















             MET-8226



                                                                    205





                                                    85


                                                                  125
                                                                  170
                                                                                           153 X 153 MM
                   REFLECTOR                 RECOMMENDED LAMP                        RIM
                                    LAMP                        POWER
                  FACET DESIGE                   LAMP TYPE                       ALUM. DIE CAST
                                     BASE                      220V AC
                 PP-A      -
                                                                          WHITE    M.WHITE  M.SILVER
                  -        -          2 X E27                2 X PLCE 23 w             0.18 amp.
                  -        -       2 X G 24 d    2 X PLC 26 w   0.62 amp.
                                                                            -        -         -
                  -        -
                                                FROSTED GLASS DIFFUSER

             MET-K311








                                                         105





                                                                            112
                                                                      145
                                                                                           125 X 220 MM
                   REFLECTOR                 RECOMMENDED LAMP                       RIM
                                    LAMP                       POWER                ALUM.  STAINLESS
                  FACET DESIGE                  LAMP TYPE                MILD STEEL
                                     BASE                      220V AC             DIE CAST  STEEL
                 PP-A      -
                                                                            -       WHITE      -
                  -        -
                                    2 X G 24 d  1 X PLC 26 w   0.31 amp.
                  -        -
                                                                            -        -         -
                  -        -
                                                ADJUSTABLE LAMP POSITION
